Description
Standard Features
- Quick & Easy Adjustment for uniform crush
- Standard Components for ease of maintenance
- 2 Sizes Available to achieve capacity requirements
- Stainless Steel options available
Upgrade to our Value-Added Brewery Package which includes the most popular accessories for brewers:
- Extended Hopper for double capacity & manual feed
- Hardened Rolls add 50% to the life of the rolls
- Flex Auger or Funnel Boot for adaptability
- Caster Wheels for ease in portability
SPECS
- Single or 3 Phase TEFC Motor with optional explosion proof (XP) upgrade
- EconoMill™ 1.5 capacity ranges up to 1,700 lbs/hr / 771 kg
- EconoMill™ 2.0 capacity ranges up to 2,000 lbs/hr / 900 kg
Technical Data | ||||||||
---|---|---|---|---|---|---|---|---|
Avg Capacity Malted Barley (bu/hr or lbs/hr) |
Avg Capacity (bu/hr) Barley/Oats |
Dimensions W / H / L |
Dimensions Weight lbs |
Rollers Size W x D |
Motor HP |
Hopper Cap. Reg Hop/ Ext. Hop lbs of Malted Barley |
Groves per inch |
|
EconoMill™ 1.5 | 50/1700 | 50/35 | 22″/34″/40″ | 275 | 6″ x 8.5″ | 1.5 | 50/100 | 4 to 12 |
EconoMill™ 2.0 | 60/2000 | 60/45 | 22″/34″/40″ | 280 | 6″ x 8.5″ | 2.0 | 50/100 | 4 to 1 |
